Name: Active Survey Monuments

Display Field: MONUMENTID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This data contains information on the location and condition of survey monuments in Bernalillo County. Both vertical and horizontal survey data are kept within the dataset, as well as destroyed or inactive monuments. Monuments are tracked by the survey staff and their condition is updated as staff reviews in-field monuments.

Copyright Text: City of Albuquerque, Department of Municipal Development; Construction Services Division

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.1912945459221264E7
YMin: 4117661.170077325
XMax: -1.180458735558081E7
YMax: 4202696.949063615
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: MONUMENT_TYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Vertical
  Label: Vertical
  Description: N/A
  Symbol:

• Value: Horizontal
  Label: Horizontal
  Description: N/A
  Symbol:

• Value: Vertical and Horizontal
  Label: Vertical and Horizontal
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:
Label Placement: esriServerPointLabelPlacementAboveRight
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 12
Font Family: Arial
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 50000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• MONUMENTID ( type: esriFieldTypeString, alias: MONUMENTID, length: 32 )
• MONUMENTSTATUS ( type: esriFieldTypeString, alias: MONUMENTSTATUS, length: 11 )
• ZONE ( type: esriFieldTypeString, alias: ZONE, length: 8 )
• DateMadeActive ( type: esriFieldTypeDate, alias: DateMadeActive, length: 8 )
• DateMadeInActive ( type: esriFieldTypeDate, alias: DateMadeInActive, length: 8 )
• NAD83LAT_DEG ( type: esriFieldTypeSmallInteger, alias: NAD83LAT_DEG )
• NAD83LAT_MIN ( type: esriFieldTypeSmallInteger, alias: NAD83LAT_MIN )
• NAD83LAT_SEC ( type: esriFieldTypeDouble, alias: NAD83LAT_SEC )
• NAD83LON_DEG ( type: esriFieldTypeSmallInteger, alias: NAD83LON_DEG )
• NAD83LON_MIN ( type: esriFieldTypeSmallInteger, alias: NAD83LON_MIN )
• NAD83LON_SEC ( type: esriFieldTypeDouble, alias: NAD83LON_SEC )
• ELIPHEIGHTMTR ( type: esriFieldTypeDouble, alias: ELIPHEIGHTMTR )
• NAD83ORDER ( type: esriFieldTypeSmallInteger, alias: NAD83ORDER )
• NAD83CLASS ( type: esriFieldTypeSmallInteger, alias: NAD83CLASS )
• NAD83_NORTH_USFT ( type: esriFieldTypeDouble, alias: NAD83_NORTH_USFT )
• NAD83_EAST_USFT ( type: esriFieldTypeDouble, alias: NAD83_EAST_USFT )
• NAD83_NORTH_MTR ( type: esriFieldTypeDouble, alias: NAD83_NORTH_MTR )
• NAD83_EAST_MTR ( type: esriFieldTypeDouble, alias: NAD83_EAST_MTR )
• GRNDTOGRIDFACTOR ( type: esriFieldTypeDouble, alias: GRNDTOGRIDFACTOR )
• MAPPINGANGLE ( type: esriFieldTypeString, alias: MAPPINGANGLE, length: 11 )
• GRS80GEOIDSEPMTR ( type: esriFieldTypeDouble, alias: GRS80GEOIDSEPMTR )
• NAD83SOURCEDATAFILE ( type: esriFieldTypeString, alias: NAD83SOURCEDATAFILE, length: 255 )
• NAD83DATELOADED ( type: esriFieldTypeDate, alias: NAD83DATELOADED, length: 8 )
• NAVD88ORTHOHGHT_USFT ( type: esriFieldTypeDouble, alias: NAVD88ORTHOHGHT_USFT )
• NAVD88ORDER ( type: esriFieldTypeSmallInteger, alias: NAVD88ORDER , Coded Values: [1: 1] , [2: 2] , [3: 3] , ...6 more... )
• NAVD88CLASS ( type: esriFieldTypeSmallInteger, alias: NAVD88CLASS , Coded Values: [1: 1] , [2: 2] , [3: 3] , ...1 more... )
• NAVD88SOURCEDATAFILE ( type: esriFieldTypeString, alias: NAVD88SOURCEDATAFILE, length: 255 )
• NAVD88DATELOADED ( type: esriFieldTypeDate, alias: NAVD88DATELOADED, length: 8 )
• FILELINKDRIVE ( type: esriFieldTypeString, alias: FILELINKDRIVE, length: 255 )
• FILELINKOBSTRUCTDIAG ( type: esriFieldTypeString, alias: FILELINKOBSTRUCTDIAG, length: 255 )
• FILELINKDRAWINGFILE ( type: esriFieldTypeString, alias: FILELINKDRAWINGFILE, length: 255 )
• Note ( type: esriFieldTypeString, alias: Note, length: 255 )
• DATASHEETLINK ( type: esriFieldTypeString, alias: DATASHEETLINK, length: 255 )
• MONUMENT_TYPE ( type: esriFieldTypeString, alias: MonumentType, length: 50 , Coded Values: [Vertical: Vertical] , [Horizontal: Horizontal] , [Vertical and Horizontal: Vertical and Horizontal] )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Description_from_Export ( type: esriFieldTypeString, alias: Description_from_Export, length: 1073741822 )
• Notes ( type: esriFieldTypeString, alias: Notes, length: 500 )
• Technician_last_checked ( type: esriFieldTypeString, alias: Technician_last_checked, length: 255 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GRND_TO_GRID_FACTOR ( type: esriFieldTypeDouble, alias: Ground to Grid Factor )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
